| TFT |
2.8 inch TFT (320*240) |
| Fingerprint Sensor |
(Energy-saving) Optical Fingerprint Sensor (Resolution : 500 DPI) |
| CPU |
32 bit CPU |
| Fingerprint Capacity |
1,000 |
| Log Capacity |
100,000 events |
| Communication |
USB (TCP/IP Optional) |
| Identification Mode |
Fingerprint, Password, Proximity Card |
| Proximity Card |
125Khz, EM4100 or other Compatible Contactless ID Card |
| USB Flash Drive Up/Download |
Available |
| Record Query |
Available (people can query their own attendance record after authentication) |
| Rotational Angle |
Total Rotational Angle |
| Indentification Time |
<= 1 s |
| FRR |
<= 0.1% |
| FAR |
<= 0.0001% |
| Operating Mode |
Off-line / Online |
| Authentication Mode |
1 : 1 , 1 : N |
| Language |
Thai, English, Korean |
| Voice Prompt |
Available |
| Bell |
Built-in Timing Bell |
| Self Test |
Available |
| Power Management |
Auto Sleep Time, Auto Power Off Time |
| Power Adapter |
DC 12V/1A |
| Operating Environment |
Operating Temp : -10 C ~ +60 C, Humidity(RH); 20% ~ 80% |
| Size of the Terminal |
180x134x36 (LxWxH) mm. |
|
